The Plastimo Offshore 75 Compass Bracket / Mini-Binnacle is a compact, front-reading compass that mounts flush on a horizontal surface. Its highly stable compass card delivers accurate readings under all weather and light conditions.
Bracket : the broad and sturdy bracket base absorbs the vibrations. Mounting can be done on any surface, whatever the angle, provided that the compass + card unit remains horizontal at all times. Bracket-mount compass can also be removed when fitted with clip-plate.
World balance, one single compass around the world. Double-dip compass designed to operate accurately in both Northern and Southern hemispheres - Zones A-B & C.
Features:
- (1) fluorescent orange lubber line for instant recognition
- Magnetic cell equipped with the exclusive "Vibration Absorber" system to resist hull pounding
- Watertight construction with one-piece molded flange and bowl
- Light bulb is integrated in bowl for even illumination
- Compass components treated for UV protection, dome is scratch resistant
- Compass universally balanced for worldwide use
- 5-year limited warranty
Specifications:
- Mount:
- Mini-binnacle : on a horizontal surface thanks to a clip-plate (included) : compass is removable.
- With bracket : mounted on a horizontal or inclined surface. Compass is removable thanks to clip-plate.
- Boat Type: Power 5 to 8 m (17 - 26 ft.)
- Compass Color (flange): White
- Bracket Color: White
- Compass Card: Conical card graduated every 5° with heading numerals every 30°
- Apparent Card Diameter: 70 mm
- Card Color:White
- Lighting: 12 - 24 Volt DC LED
- Installation Cut-Out: 66 mm dia.
- Regulatory: ISO 613 compliant
|
